Success TPT-522N - metal and PVC pipe locator with water leak detection function
The modern multifunctional set for metal and non-metal utilities tracing and water leak detection from any pipes.
Key features
- The set combines three devices:
- water leak detector with acoustic sensor;
- cable and pipe locator with acoustic sensor;
- cable and pipe locator with electromagnetic sensor.
- Includes sensitive acoustic sensor with replaceable contact rod and removable composite handle.
- Audio signal spectrum visualization for accurate pipeline location.
- Tracing of plastic pipes at the distance up to 150 m using an acoustic impact device.
screen
detection
depth
detection
depth
distance
Application of metal and non-metal pipeline locator with water leak detection function Success TPT-522N
- Location of power and signal cables, armored fiber optic cables, pipelines of electrically conductive materials at a depth of up to 6 m and at a distance of up to 5 km from the transmitter connection point.
- Tracing of pipelines with or without the trench by electromagnetic and acoustic methods.
- Cable fault location by electromagnetic and acoustic methods.
- Survey of the ground before the excavation works.
- Locate water leaks on the depth up to 3 m.
One device combines an electromagnetic signal transmitter and an impact mechanism.
Features of metal and non-metal pipeline locator with water leak detection function Success TPT-522N
Metal and PVC pipe locator with water leak detection function Success TPT-522N – multifunctional 3 in 1 set:
1. Cable and pipe locator with acoustic sensor
- Use of power transmitter AG-144.1 (7.5...180 W) and an impact device UM-112.
- Protection from redirection to other objects (pipes).
- High location accuracy.
Acoustic method is used to locate metal and non-metal pipelines, when tracing metal pipelines in conditions of high industrial interference, when tracing is difficult (if there are nearby communications, such as pipes, cables, metal objects; industrial interference, such as power lines, railway and tram lines, etc.).
2. Cable and pipe locator with electromagnetic sensor
- Power from 7.5 to 180 W.
- Automatic load adjustment, which allows to send a certain signal power to a random load.
- Alternating sinusoidal current (constant or short-term pulses).
- Performance up to 18 hours when low power is selected.
3. Water leak detector with acoustic sensor
- Sensitive acoustic sensor.
Features of AP-027 receiver
- Advanced digital location receiver.
- Large LCD display with switchable modes.
- Sound output to the built-in speaker and the operator's headphones.
- Vast range of supported frequencies (50 / 100 / 512 / 1024/ 8192 / 32768 Hz, WideBand 50…8600Hz).
- Ability to connect an acoustic sensor (water leak detector / cable flaw detector functions).
- Enclosure protection class IP54 against external influences.
Features of AG-144.1 transmitter
- Choice of output power of the transmitter (from 7,5 up to 180 W).
- Automatic adjustment at the wide range of the load resistance, automatic re-adjustment using the transmitter.
- Long working time from accumulator.
Description of impact device UM-112
It is used for producing the sound impacts on the pipe surface for acoustic tracing of non-metal and metal pipelines. The sound produced with the impact device is spread along the pipeline and, through the ground, picked-up with the acoustic sensor connected to the receiver. After being amplified and filtered in the receiver, the sensor signal is indicated on the screen and transmitted to headphones.
AP-027 operation for utilities tracing
Move to the supposed utility location - an energized cable or a pipe. During the operation there will be information on the screen and sound in the headphones.
- The signal is low on the screen and in the headphones, it means the utility is far away from the operator.
- The closer to the utility the higher is the signal on the screen and the louder is the sound in the headphones.
- The operator is above the utility, the signal is maximum.
- The signal is less, it means the leakage was behind.
Acoustic sensor AD-327 operation for water leaks detection
Move along the pipe to the supposed place of water leakage. During the operation there will be the following indication on the screen:
- The signal is low on the screen and in the headphones, there is no signifi cant noise.
- The closer to the place of leakage the higher is the signal on the screen and the louder is the sound in the headphones.
- The operator is above the place of leakage, the signal is maximum.
- The signal is less, it means the leakage was behind.
Metal and PVC pipe locator with water leak detection function Success TPT-522N is recommended for application in the following industries
- Public utilities.
- Heat and water supply.
- Gas distribution networks.
Specifications of AP-027 receiver
Parameter | Tracing | Leak detection |
---|---|---|
Type of accepted signal | Uninterrupted /pulse | Uninterrupted signal |
Frequencies of the receiver’s filter | Central frequency of quasi-resonant filter 50…60 Hz, 100…450 Hz through 50 Hz, 120…540 Hz through 60 Hz, 512 Hz / 1024 Hz / 8192 Hz / 33 kHz | - Range limitation "below" 0,1 / 0,15 / 0,21 / 0,31 / 0,45 / 0,65 / 0,95 / 1, 38 kHz; - Range limitation "above" 2,00 / 1,38 / 0,95 / 0,65 / 0,45 / 0,31 / 0,21 / 0, 15 kHz |
"Broadband" (operating mode) | 0,05…8,6 kHz | 0,09…2,20 kHz |
Gain factor | 100 dB | |
Visual indication | Liquid-crystal display-symbols and meaning of the chosen modes and parameters: - animated (moving) scale of the output signal level; - digital value and animated (moving) scale of the output signal level; - graphic (moving diagram) of the output signal level; - frequency content of the output signal level; - digital and graphic display of output signal levels kept in the "memory" |
|
Sound indication | - Headphones natural broadband or filtered signal | |
- Headphones-synthesized sound. Frequency modulation; - Built-in emitter - synthesized sound. Frequency modulation |
- | |
Supply | - voltage 4...7 V; - alkaline batteries АА type 1,5 V (4 pcs.) |
|
Time of continuous operation not less than | 20 hours | |
Automatic shutdown when the device is not active | After 30 minutes of inactivity | |
Ambient temperature | -20...+50°С | |
Ingress protection rating | IP54 | |
Weight of the electronic unit | 0,46 kg | |
Receiver AP-027 dimensions | 220x102x42 mm |
Specifications of AG-144.1 transmitter
Parameter | Value | ||||
---|---|---|---|---|---|
Transmitted signal frequencies, Hz | |||||
Frequencies SIN f1 / f2 / f3, ±0.1% | 512 / 1024 / 8192 | ||||
Shock repetition frequencies, low / medium / high frequency | 0.5 / 1 / 2 | ||||
Transmission modes | |||||
"SIN" "contin" | Continuous sine transmission | ||||
"SIN" "_П_" | Short-time pulsing of sine signal | ||||
- pulse duration, ms | 100 | ||||
- pulse repetition rate, Hz | 1 | ||||
"SIN" "3 freq" | Three-frequency – sine signal pulsing with repetition of frequencies f1, f2, f3 | ||||
- pulse duration, ms | 100 | ||||
- pulse repetition rate, Hz | 2 | ||||
"SHOCK" pulse duration | Transmission of shock pulses, set automatically | ||||
Output parameters of sine transmission | |||||
Maximum output voltage, V: | |||||
- at autonomous power supply | 220 | ||||
- with the 12/24 V external accumulator added | 330 | ||||
- at power supply from the network unit | 140 | ||||
Output power provided due to self-matching (fully-charged accumulators), ±20%: | |||||
- at autonomous power supply (12/24 V) | |||||
Modes: - continuously - pulses 8192 Hz and 3 freq |
Pout, W | 7.5 | 15 | 30 | 60 |
Rload, Ω | 0.1...300 | 0.15...660 | 0.3...1.300 | 0.6...660 | |
Modes: - pulses 512 and 1,024 Hz |
Pout, W | 15 | 30 | 60 | 120 |
Rload, Ω | 0.15...660 | 0.3...330 | 0.6...660 | 1.2...330 | |
- with supply voltage built up to 36 V with the use of the 12/24 V external accumulator | |||||
Modes: - continuously - pulses 8192 Hz and 3 freq |
Pout, W | 45 | 90 | ||
Rload, Ω | 0.45...2.000 | 0.9...1.000 | |||
Modes: - pulses 512 and 1,024 Hz |
Pout, W | 90 | 180 | ||
Rload, Ω | 0.9...1.000 | 1.8...500 | |||
- from the network power supply unit | |||||
Modes: - continuously - pulses 8192 Hz and 3 freq |
Pout, W | 18 | 36 | ||
Rload, Ω | 1.8...800 | 0.4...400 | |||
Modes: - pulses 512 and 1,024 Hz |
Pout, W | 36 | 72 | ||
Rload, Ω | 0.4...400 | 0.7...200 | |||
Permissible load resistance | any (0…∞) Current limitation on «low-resistance» loads. Broken cable capacitance operation |
||||
Matching with load | Automatic, providing for the target power gaining in the load | ||||
Power supply sources | |||||
Built-in accumulator set | Two lead-acid sealed accumulators 12 V/7 Ah (AGM technology) with switch-over: 12V/14Ah or 24V/7Ah | ||||
Network unit for accumulators operation or charging | Output voltage 15 V, output current up to 6.7 A | ||||
Source duration depending on power that was initially gained as a result of self-matching (ambient temperature 0°С), minimum | |||||
- continuous generation | Duration, hours | 1.7 | 3.7 | ||
Pout, W | 60 autonomously / 90 with add. acc. | 30 autonomously / 45 with add. acc. | |||
- one-frequency pulses | Duration, hours | 8 | 18 | ||
Pout, W | 120 autonomously / 180 with add. acc. | 60 autonomously / 90 with add. acc. | |||
- three-frequency pulses | Duration, hours | 8 | 18 | ||
Pout, W | 60 autonomously / 90 with add. acc. | 30 autonomously / 45 with add. acc. | |||
- transmission of shock pulses | Duration, hours | 8 | 18 | ||
Pout, W | "hf" 2 Hz |
"mf" 1 Hz |
|||
Maximum time of self-contained accumulators charging, hours | 4 | ||||
Functional Specific Features | |||||
Automatic functions | - self-matching (target power gaining in the load); - specific program for transmitting antenna control; - built-in automatic charger; - "autodetection" of transmitting antenna and shock device connection and disconnection |
||||
Automatic disabling of transmission (charging) | - when accumulators are charged below the permitted rate (prevention of deep irreversible discharge); - when external source voltage does not correspond to the transmission / charging mode; - when the network source mode is switched over during charging; - when the output is short-circuited during matching; - when the transmission mode does not correspond to the transmitting antenna or shock device presence / absence at the output |
||||
Automatic repeated matching | - when the steady-state output power increases due toinadvertent drop in load resistance; - when the frequency / transmission mode "SIN" is switched over; - when certain source voltage changes occur |
||||
Types of connected loads at transmission "SIN" | - direct connection to the facility with current "return" via the cable cord or armature; - direct connection to the facility with current "return" via ground by means of a ground pin; - loop connection with the use of the transmitting loop antenna at the 8192 Hz (selected automatically at antenna connection); - loop connection with the use of the loop clamp (selection of the cable from a bundle) |
||||
Design parameters | |||||
Output power amplifier | pulsed, technology CLASS D(BD), coefficient of efficiency > 80% | ||||
Indication | Light-emitting diodes: - three-colour "source" and "out"; - source voltage and status; - output power and status red « »; - possible or present "dangerous" output voltage (>24V) |
||||
Control | Push-button switches - three-position switches: - "FREQ" of the output signal "SIN, Hz" or "SHOCK" of pulse repetition; - "MODE", "SIN" – sine transmission type; - "START" of transmission / charging and selection of half / full power "SIN" available for this source two-position switches – "SOURCE": - "EXTERN" – capacity / power build-up with the use of the external accumulator or selection of operation / charging from the network unit; - "INTERN" – selection of the 12 V / 24 V internal source voltage for changing the specified power (by 4 times in autonomous mode) button « »: - loading in potentially "dangerous" mode with "unlimited" output voltage (Uout can be >24 V) |
||||
Overall dimensions of the electronic unit (case), max., mm | 220х160х145 | ||||
Weight of the electronic unit, max., kg | 8.2 | ||||
Operation conditions | |||||
Permissible ambient temperature range at operation | -30…+60°С | ||||
Climatic protection class | IP54 (dust-water-shock-proof casing) |
Basic set
№ | Name | Quantity |
---|---|---|
1 | Receiver AP-027 | 1 pcs. |
2 | Transmitter АG-144.1 | 1 pcs. |
3 | Inductive antenna IEM-301.3 | 1 pcs. |
4 | Electromagnetic sensor EMD-247 | 1 pcs. |
5 | Acoustic sensor AD-327 | 1 pcs. |
6 | Impact device UM-112 | 1 pcs. |
7 | Headphones | 1 pcs. |
8 | Contact magnetic AG120.02.090 | 2 pcs. |
9 | Grounding rod AG110.02.004 | 2 pcs. |
10 | Operation manual | 1 pcs. |
Accessories
Appliable with transmitters AG-105, AG-107, AG-120 and AG-144.1.
Appliable with transmitters AG-105, AG-107, AG-120 and AG-144.1.
Appliable with transmitters AG-105, AG-107, AG-120 and AG-144.1.
Compatible with the receivers АP-019, AP-027.
Compatible with the receivers АP-019, AP-027.
Compatible with the receivers АP-019 and AP-027.
Sensor is used for precise location of a single cable in a bunch of other cables.
Used for pipeline leak detection in hard-to-reach places and for isolation valves diagnostics.
Compatible with the receivers AP-019 and AP-027.
It is used for the selection of the cable from a bunch, for location of internal wiring and cable fault location.
Extra grounding wire and rod for better quality of underground utility location.
Set of type C rechargeable accumulators and charger for AP-019 and AG-105.
